Geodata Examples

This page lists all geodata examples that are included in the Tinman 3D SDK.

All 3rd party geodata that is consumed by the geodata examples is subject to the respective terms of use. The same may apply to the generated output datasets. For legal advise on how to use that data, please refer to the respective geodata provider.

Overview

Each geodata example contains the following items:

  • Input geodata (data/*)
    In case that 3rd party geodata is not included in the SDK download, the file corresponding *.tms script file contains a description of the required input geodata files, and instructions on how to download them.

  • Processing script (*.tms)
    The Geodata Processor can be used to run the processing scripts from the command line. The Workshop Application can be used to open the geodata examples project src.twp/geodata_examples.twp, which references all processing scripts.

    Some geodata examples require that GDAL is installed.
  • Batch file (*.cmd)
    Shows how to invoke the tinmanpc tool from the command line.

  • Output raster datasets (*.hgt)
    The output datasets are not included in the SDK download. They can be generated from scratch by running the processing scripts, which requires to download the input data first.

    Download ready-to-use output datasets here: https://data.tinman3d.online.

Download

The Demo Application will stream raster datasets from their online URLs, if they cannot be found locally. To run in offline mode, please download the datasets and put them into the corresponding SDK path:

"https://data.tinman3d.online/geo/WorldMachine/Lakes.hgt" (1)
        "$(SDK_DIR)/data.bulk/geo/WorldMachine/Lakes.hgt" (2)
//                            \________________________/
//                             This part is always identical.
1 URL to the online dataset
2 Path to the dataset in the data.bulk SDK directory
Due to the size of the dataset files, we recommend to use a download manager that can handle broken connections.

Alternatively, you can use the Workshop Application to bulk download all raster datasets, by running the following script target:

download_bulk (1)
src.twp/geodata_examples.tms (2)
src.twp/geodata_examples.twp (3)
1 The script member to run
2 The enclosing script file
3 The enclosing Workshop Application project
Verify the MD5 checksum of each downloaded dataset to make sure all data has been downloaded correctly.

Earth

This section contains geodata examples for the Earth.

To see this data, run the Demo Application and visit one of the predefined location bookmarks in Tutorial_23_Earth.

Antarctica

Input

data\geo\Antarctica\data\

Output

data\geo\Antarctica\antarctica.hgt

Script

data\geo\Antarctica\antarctica.tms

URL

https://data.tinman3d.online/geo/Earth/Antarctica/antarctica.hgt (459 MB)

ASTER GDEM 3

Input

data\geo\Earth\ASTER GDEM 3\data\

Output

data\geo\Earth\ASTER GDEM 3\aster_gdem_3.hgt

Script

data\geo\Earth\ASTER GDEM 3\aster_gdem_3.tms

URL

https://data.tinman3d.online/geo/Earth/ASTER%20GDEM%203/aster_gdem_3.hgt (112 GB)

ASTER WBD 1

Input

data\geo\Earth\ASTER WBD 1\data\

Output

data\geo\Earth\ASTER WBD 1\aster_wbd_1.hgt

Script

data\geo\Earth\ASTER WBD 1\aster_wbd_1.tms

URL

https://data.tinman3d.online/geo/Earth/ASTER%20WBD%201/aster_wbd_1.hgt (4.2 GB)

The classification codes are mapped to terrain material IDs as follows:

Ocean

0% coverage

River

100% coverage with material ID 1

Lake

100% coverage with material ID 2

Land

100% coverage with material ID 3

To get a solid dataset, use material swizzle to turn coverage into material ID 0.

Blue Marble 2

Input

data\geo\Earth\BlueMarble 2\data\

Output

data\geo\Earth\BlueMarble 2\bluemarble2.hgt

Script

data\geo\Earth\BlueMarble 2\bluemarble2.tms

URL

https://data.tinman3d.online/geo/Earth/BlueMarble%202/bluemarble2.hgt (1.3 GB)

EGM2008

Input

data\geo\Earth\EGM2008\data\

Output

data\geo\Earth\EGM2008\egm2008.hgt

Script

data\geo\Earth\EGM2008\egm2008.tms

URL

https://data.tinman3d.online/geo/Earth/EGM2008/egm2008.hgt (23.2 MB)

EGM96

Input

data\geo\Earth\EGM96\data\

Output

data\geo\Earth\EGM96\egm96.hgt

Script

data\geo\Earth\EGM96\egm96.tms

URL

https://data.tinman3d.online/geo/Earth/EGM96/egm96.hgt (2.0 MB)

Elevation1

Input

data\geo\Earth\Elevation1\data\

Output

data\geo\Earth\Elevation1\elevation1.dem.hgt

data\geo\Earth\Elevation1\elevation1.img.hgt

Script

data\geo\Earth\Elevation1\elevation1.tms

URL

https://data.tinman3d.online/geo/Earth/Elevation1/elevation1.dem.hgt (248 MB)

https://data.tinman3d.online/geo/Earth/Elevation1/elevation1.img.hgt (1.3 GB)

GEBCO

Input

data\geo\Earth\GEBCO\data\

Output

data\geo\Earth\GEBCO\gebco.hgt

Script

data\geo\Earth\GEBCO\gebco.tms

URL

https://data.tinman3d.online/geo/Earth/GEBCO/gebco.hgt (1.6 GB)

GMTED2010

Input

data\geo\Earth\GMTED 2010\data\

Output

data\geo\Earth\GMTED 2010\gmted2010.ds30.hgt

data\geo\Earth\GMTED 2010\gmted2010.ds15.hgt

data\geo\Earth\GMTED 2010\gmted2010.ds75.hgt

Script

data\geo\Earth\GMTED 2010\gmted2010.tms

URL

https://data.tinman3d.online/geo/Earth/GMTED%202010/gmted2010.ds30.hgt (157 MB)

https://data.tinman3d.online/geo/Earth/GMTED%202010/gmted2010.ds15.hgt (517 MB)

https://data.tinman3d.online/geo/Earth/GMTED%202010/gmted2010.ds75.hgt (1.8 GB)

Landsat 7 ETM+

Input

data\geo\Earth\Landsat\data\

Output

data\geo\Earth\Landsat\landsat.hgt

Script

data\geo\Earth\Landsat\landsat.tms

URL

https://data.tinman3d.online/geo/Earth/Landsat/landsat.hgt (554 MB)

MODIS Water Mask

Input

data\geo\Earth\MODIS Water\data\

Output

data\geo\Earth\MODIS Water\modis_water.hgt

Script

data\geo\Earth\MODIS Water\modis_water.tms

URL

https://data.tinman3d.online/geo/Earth/MODIS%20Water/modis_water.hgt (90.3 MB)

NED 1/3"

Input

data\geo\Earth\NED 13\data\

Output

data\geo\Earth\NED 13\ned13.hgt

Script

data\geo\Earth\NED 13\ned13.tms

URL

https://data.tinman3d.online/geo/Earth/NED%2013/ned13.hgt (31.9 GB)

NED 1/9"

Input

data\geo\Earth\NED 19\data\

Output

data\geo\Earth\NED 19\ned19.hgt

Script

data\geo\Earth\NED 19\ned19.tms

URL

https://data.tinman3d.online/geo/Earth/NED%2019/ned19.hgt (42.6 GB)

swissALTI3D

Input

data\geo\Earth\swissALTI 3D\data\

Output

data\geo\Earth\swissALTI 3D\swissalti_3d.hgt

Script

data\geo\Earth\swissALTI 3D\swissalti_3d.tms

URL

https://data.tinman3d.online/geo/Earth/swissALTI%203D/swissalti_3d.hgt (136 GB)

Mars

This section contains geodata examples for Mars.

To see this data, run the Demo Application and visit one of the predefined location bookmarks in Tutorial_25_Mars.

HiRISE

Input

data\geo\Mars\HiRISE\data\

Output

data\geo\Mars\HiRISE\hirise.hgt

data\geo\Mars\HiRISE\hirise.dtm.hgt

Script

data\geo\Mars\HiRISE\hirise.tms

URL

https://data.tinman3d.online/geo/Mars/HiRISE/hirise.hgt (395 MB)

https://data.tinman3d.online/geo/Mars/HiRISE/hirise.dtm.hgt (57.8 MB)

Mars Express

Input

data\geo\Mars\MarsExpress\data\

Output

data\geo\Mars\MarsExpress\mex.hgt

data\geo\Mars\MarsExpress\mex.dtm.hgt

Script

data\geo\Mars\MarsExpress\mex.tms

URL

https://data.tinman3d.online/geo/Mars/MarsExpress/mex.hgt (65 MB)

https://data.tinman3d.online/geo/Mars/MarsExpress/mex.dtm.hgt (38.5 MB)

mars marsexpress
Figure 16. Mars Express

Mars Digital Image Model

Input

data\geo\Mars\MDIM\data\

Output

data\geo\Mars\MDIM\mdim.hgt

Script

data\geo\Mars\MDIM\mdim.tms

URL

https://data.tinman3d.online/geo/Mars/MDIM/mdim.hgt (2.9 GB)

Mars Orbiter Camera

Input

data\geo\Mars\MOC\data\

Output

data\geo\Mars\MOC\moc.hgt

Script

data\geo\Mars\MOC\moc.tms

URL

https://data.tinman3d.online/geo/Mars/MOC/moc.hgt (1.7 GB)

Mars Orbiter Laser Altimeter

Input

data\geo\Mars\MOLA\data\

Output

data\geo\Mars\MOLA\mola.hgt

Script

data\geo\Mars\MOLA\mola.tms

URL

https://data.tinman3d.online/geo/Mars/MOLA/mola.hgt (1.3 GB)

Moon

This section contains geodata examples for the Moon.

To see this data, run the Demo Application and visit one of the predefined location bookmarks in Tutorial_24_Moon.

Lunar Recon. Orbiter Camera

Input

data\geo\Moon\LROC\data\

Output

data\geo\Moon\LROC\lroc.wac.dtm.hgt

data\geo\Moon\LROC\lroc.wac.emp.hgt

data\geo\Moon\LROC\lroc.wac.hgt

data\geo\Moon\LROC\lroc.nac.dtm.5m.hgt

data\geo\Moon\LROC\lroc.nac.dtm.2m.hgt

data\geo\Moon\LROC\lola.118m.hgt

data\geo\Moon\LROC\lola.30m.hgt

data\geo\Moon\LROC\lola.20m.hgt

data\geo\Moon\LROC\lola.10m.hgt

data\geo\Moon\LROC\lola.5m.hgt

data\geo\Moon\LROC\lola.sites.hgt

data\geo\Moon\LROC\sldem2015.hgt

Script

data\geo\Moon\LROC\lroc.tms

URL

https://data.tinman3d.online/geo/Moon/LROC/lroc.wac.dtm.hgt (1.6 GB)

https://data.tinman3d.online/geo/Moon/LROC/lroc.wac.emp.hgt (599 MB)

https://data.tinman3d.online/geo/Moon/LROC/lroc.wac.hgt (1.0 GB)

https://data.tinman3d.online/geo/Moon/LROC/lroc.nac.dtm.5m.hgt (9.1 GB)

https://data.tinman3d.online/geo/Moon/LROC/lroc.nac.dtm.2m.hgt (13.8 GB)

https://data.tinman3d.online/geo/Moon/LROC/lola.118m.hgt (1.6 GB)

https://data.tinman3d.online/geo/Moon/LROC/lola.30m.hgt (943 MB)

https://data.tinman3d.online/geo/Moon/LROC/lola.20m.hgt (1.4 GB)

https://data.tinman3d.online/geo/Moon/LROC/lola.10m.hgt (1.1 GB)

https://data.tinman3d.online/geo/Moon/LROC/lola.5m.hgt (893 MB)

https://data.tinman3d.online/geo/Moon/LROC/lola.sites.hgt (114 MB)

https://data.tinman3d.online/geo/Moon/LROC/sldem2015.hgt (5.3 GB)

Other

This section contains miscellaneous geodata examples.

Bennu

Input

data\geo\Bennu\data\

Output

data\geo\Bennu\bennu.hgt

Script

data\geo\Bennu\bennu.tms

URL

https://data.tinman3d.online/geo/Bennu/bennu.hgt (663 MB)

Mercury

Input

data\geo\Mercury\data\

Output

data\geo\Mercury\mercury.dem.hgt

Script

data\geo\Mercury\mercury.tms

URL

https://data.tinman3d.online/geo/Mercury/mercury.dem.hgt (127 MB)

New Horizons

Input

data\geo\Pluto\NewHorizons\data\

Output

data\geo\Pluto\NewHorizons\charon.dem.hgt

data\geo\Pluto\NewHorizons\charon.img.hgt

data\geo\Pluto\NewHorizons\pluto.dem.hgt

data\geo\Pluto\NewHorizons\pluto.img.hgt

Script

data\geo\Pluto\NewHorizons\new_horizons.tms

URL

https://data.tinman3d.online/geo/Pluto/NewHorizons/charon.dem.hgt (20.6 MB)

https://data.tinman3d.online/geo/Pluto/NewHorizons/charon.img.hgt (23.5 MB)

https://data.tinman3d.online/geo/Pluto/NewHorizons/pluto.dem.hgt (202 MB)

https://data.tinman3d.online/geo/Pluto/NewHorizons/pluto.img.hgt (102 MB)

Planets

Input

data\geo\Planets\data\

Output

data\geo\Planets\Jupiter.hgt

data\geo\Planets\Mars.hgt

data\geo\Planets\Mercury.hgt

data\geo\Planets\Neptune.hgt

data\geo\Planets\Pluto.hgt

data\geo\Planets\Saturn.hgt

data\geo\Planets\Sun.hgt

data\geo\Planets\Uranus.hgt

data\geo\Planets\Venus.hgt

Script

data\geo\Planets\Planets.tms

URL

https://data.tinman3d.online/geo/Planets/Jupiter.hgt (25.6 MB)

https://data.tinman3d.online/geo/Planets/Mars.hgt (117 MB)

https://data.tinman3d.online/geo/Planets/Mercury.hgt (1.5 MB)

https://data.tinman3d.online/geo/Planets/Neptune.hgt (349 KB)

https://data.tinman3d.online/geo/Planets/Pluto.hgt (3.1 MB)

https://data.tinman3d.online/geo/Planets/Saturn.hgt (1.2 MB)

https://data.tinman3d.online/geo/Planets/Sun.hgt (767 KB)

https://data.tinman3d.online/geo/Planets/Uranus.hgt (176 KB)

https://data.tinman3d.online/geo/Planets/Venus.hgt (1.2 MB)

Racing Track

Input

data\geo\RacingTrack\data\

Output

data\geo\RacingTrack\RacingTrack.hgt

Script

data\geo\RacingTrack\RacingTrack.tms

URL

https://data.tinman3d.online/geo/RacingTrack/RacingTrack.hgt (2.8 MB)

other racingtrack
Figure 25. Example Terrain, created by Christian Femmer aka. Duion

Released under creative commons Attribution 3.0 Unported license (CC-BY 3.0)

"This license is acceptable for Free Cultural Works.

You are free:

to Share - to copy, distribute and transmit the work
to Remix - to adapt the work
to make commercial use of the work

Under the following conditions:

You must attribute the work in the manner specified by the author or licensor (but not in any way that suggests that they endorse you or your use of the work)"

Skybox

Input

data\geo\Skybox\data\

Output

data\geo\Skybox\Skybox.hgt

Script

data\geo\Skybox\Skybox.tms

URL

https://data.tinman3d.online/geo/Skybox/Skybox.hgt (12.7 MB)

Venus

Input

data\geo\Venus\data\

Output

data\geo\Venus\venus.dem.hgt

data\geo\Venus\venus.img.hgt

Script

data\geo\Venus\venus.tms

URL

https://data.tinman3d.online/geo/Venus/venus.dem.hgt (28.3 MB)

https://data.tinman3d.online/geo/Venus/venus.img.hgt (48.6 MB)

World Machine

Input

data\geo\WorldMachine\Lakes\

Output

data\geo\WorldMachine\Lakes.hgt

Script

data\geo\WorldMachine\WorldMachine.tms

URL

https://data.tinman3d.online/geo/WorldMachine/Lakes.hgt (474 MB)

Commercial

This section shows some examples for high-quality commercial geodata.

Typically, commercial geodata is properly geo-referenced and is delivered in handy pieces.

Airbus Defence & Space

Elevation1 Digital Surface Model

airbus.01
Figure 29. Elevation1 by Airbus Defence & Space (Mashhad, Iran)
airbus.02
Figure 30. Elevation1 by Airbus Defence & Space (Musan, North Korea)

This geodata product comes in handy pieces of 1m DEM and 50 cm imagery.

WorldDEM™

This geodata product is a global 12m DEM.

airbus.03
Figure 31. WorldDEM™ by Airbus Defence & Space (Oxford, UK)
airbus.04
Figure 32. WorldDEM™ by Airbus Defence & Space (Quintana, Uruguay)
airbus.05
Figure 33. WorldDEM™ by Airbus Defence & Space (Yakeshi, China)

PlanetObserver

This geodata is nicely wrapped in GeoTIFFs, which can be imported on-the-fly.

VHR Imagery - "Very High Resolution Imagery on Demand"

planetobserver.01
Figure 34. PlanetAIR by PlanetObserver (Mandelieu, France)

PlanetSAT - "Global Satellite Imagery Basemap"

The PlanetSAT product is a direct high-quality replacement for the free Landsat7 imagery.

planetobserver.02
Figure 35. PlanetSAT 15 by PlanetObserver (Tehran, Iran)

PlanetDEM - "Enhanced Global Digital Elevation Model"

The PlanetDEM product is a direct high-quality replacement for the free ASTER GDEM 3.

planetobserver.03
Figure 36. PlanetDEM 30 Plus by PlanetObserver (Alaska)
